Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 121

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 121
D !! 12 … reducing-gear shaft, 46, carrying the cam-roller movement for theexhaust valve, the spark-breaker cam, and contact bar, 37, and theregulating screw, 39. The atomizer or vaporizer connects with the airinlet at 24, the air cock for starting at 19. The other parts are self-explained. EXPLOSIVE MOTOR…

Mechanical movements
