Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 129

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 129
HYDRAULIC POWER AND APPLIANCES. 125 piston, we see that when it is at one end of its travel the tubes arepartially covered by it, and if they are sufficiently wide, they com-municate with each other on the same side of the piston. But as thelatter moves away from the extreme points, the tubes are…

Mechanical movements
