Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 130

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 130
cylinder, and is cham-bered on opposite sides of its periph-ery, leaving a partition, F, which is provided with a spring packing, G,at its edge. The chambers, H H, are entirely separate from eachother when the piston is inserted in the casing. One chamber com-municates by means of an opening, d,… … 293. CENTRIFUGAL PUMP. German type. disk receives the

Mechanical movements
