Questions and answers on pumps and pumping machinery (1912)
Wakeman, William Henry, 1855- [from old catalog] · Chicago, The Joseph G. Branch publishing company · leaf 72
F1&.34- PUMPS AND PUMPING MACHINERY. 61 A. It may be compared to a curved pipe, pivotedat the center and fed with water at the same point.This pipe is turned rapidly like a pin-wheel, as illus- … RO.35 trated in Fig. 36. This water is forced into a casingwhich gradually widens, as shown at 2, until itbroadens into the discharge passage, 3. 230. Q. How is water taken by this pump? 62 QUESTIONS AND ANSWERS ON A. It is drawn into the central opening, 4. 231. Q. What course does it follow after…
Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
