Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 165

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 165
theoperation of the burner to be under-stood. The oil enters the tube, A,under pressure, and makes its exitthrough a cylindrico-conic ajutageplaced within the lamp. This ajutageis capped by a second ajutage, B,serving for the passage of the air andthe atomized oil. The air entersthrough a conduit,… … 385. GASOLINE TORCH. Gasoline forcedinto a small retort, previously heated by firing asmall quantity of gasoline in the cup below, is vapor-ized and issues through the perforated top of theretort in a brilliant light. About 3 feet below thereservoir for the burner is sufficient for the…

Mechanical movements
