Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 170

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 170
Drain Cock SECTION X. ELECTRIC POWER ANDDEVICES. 164 Section X. ELECTRIC POWER AND DEVICES. 392. ELECTRIC CABLE-MAKING MACHINE. A revolvingframe carrying the required number of wire bobbins. The strands aregathered by passing through a die and covered in reverse wrappings … by passing through revolving heads mounted with paper spools, andthrough dies to compact the paper winding. The cable is drawn bythe take-up wheel, which is conical on the face and draws by severalfrictional windings. 393. CHLORIDE ACCUMULATOR or storage battery. Thealternate perforated plates are…

Mechanical movements
