Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 174

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 174
nlyinsulating material that has been found suitable for the insulation ofcommutators. The sleeve s is insulated by a cylindrical body insula-tion m, against which the bars are clamped. The end insulations iand / are of mica built up into conical form and pressed into shape insuitable molds. With… … -7- ELECTRIC POWER AND DEVICES 408. SPRING BINDING POST. A quickmethod of changing electric-wire connections—press the spring and push in the wire, A most convenient binding post.
