Hartford Steam Boiler Inspection and Insurance Company · Hartford, Ct. : Hartford Steam Boiler Inspection and Insurance Co · leaf 206
eaf of the ring. Then the total tension,acting normally upon the little rectangle whose width is dx and whoselength is s, is fs.dx. This force has a horizontal component, parallel to OX,whose magnitude is sin D.fs.dx, as will be understood by reference to Fig. 29.(It is to be noted that 8 is equal… … ^ o X ». <! <8 !-J-J UJ zr:00 Fig. 28. — A Unit of the Ring. the axis of the shell, when the circumferential stress is a tension; and if weintegrate it between the limits x = o and x = h, we shall obtain the total forceacting upon the shaded face of Fig. 28, in a direction horizontal and…
Locomotives · Steam-boiler explosions
Internet Archive · Carnegie Library of Pittsburgh · Public Domain Mark 1.0. Free to use for anything.
