Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 177

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 177
closed by pressing a button, the armature end of the lever B is pulleddown, releasing the upper end of the vertical lever D, which also serves as a hammer, striking the lug on the pawlE, throwing it out of engagement withthe ratchet, thus allowing the shaft of thestop to revolve and close the valve…

Mechanical movements
