Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 179

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 179
421. ELECTRICALLYDRIVEN SEWING MA-CHINE. The armature ison the shaft that operatesthe needle bar and shuttlewith a rheostat to controlthe speed. A pinion on thedriving shaft meshing inan internal toothed wheelwith handle enables man-agement of the sewing ma-chine by hand. ELECTRIC POWER AND…

Mechanical movements
