Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 203

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 203
499. THE MANIPEDE CATAMARAN. Operated by feet orhands on levers with sprocket wheel and chain to a paddle wheel.Steered by a rocking seat, or by hand. 198 NAVIGATION, VESSELS, MARINE APPLIANCES, ETC. Usual Plan … 500. TYPES OF SHALLOW-DRAUGHT SCREW-PROPELLEDBOATS. Yarrow type. Vessels of this class have been constructed with t he propellerworking in a tunnel,so that though thepropeller used begreater in diameterthan the draught, yetit always works insolid water, since thewater, owing to theair being driven…
