Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 205

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 205
508. Plan with fig-ured measures andscale. 509. SUBMARINE CABLE GRAPNEL.With removable prongs for easy repair. By an\ overstrain, by the prong catching in a rock or^ other obstruction, the small rivet, B, will shear offand release the prong. Four prongs to each grap-nel. Much used in the repair of…

Mechanical movements
