Steel ships, their construction and maintenance : a manual for shipbuilders, ship superintendents, students, and marine engineers (1901)
Walton, Thomas · London : Charles Griffin & Co. ; Philadelphia : Lippincott · leaf 324
commonly known as the spectacles. This is usually asteel casting, in one piece, firmly bolted through the fore post of the sternframe, and securely riveted to the bossed plating of the shell. The notesupon the diagrams are sufiicient to give a general idea of this mode ofconstruction (figs. 157 and… … (&.) Transverse Section (enlarged). Fig. 153.—Connection of Struts with Stern Frame in Twin-ScrewSteamers : a, Elevation : &, Transverse Section, 240 STEEL SHIPS. WATERTIGHT FLAT ^ Y ; §1 ■
Naval architecture · Ships, Iron and steel
Internet Archive · University of Connecticut Library · Public Domain Mark 1.0. Free to use for anything.
