Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 221

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 221
ke, and also oneon the rear wheel hub. 556. TYPES OF MOTOR BICY-CLES. Ladies Ivel. The motor isplaced beneath the lower front frameand drives by belt to a pulley. Carbu-reter, igniter, and fuel at the back of theseat post. A skirt shield covers the motorand belt. 557. STEAM SURREY.The boiler is… … ROAD AND VEHICLE DEVICES, ETC. 217 558. STEAM FREIGHT WAGON. Adams Express type. Anoil fuel burner under a vertical tube boiler.
