Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 227

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 227
566. TROLLEY-CARSAXDER. A sand box withgate and stirring pin on the gateis operated through the con-necting rod by a push buttonand bell crank. … 567. LOCOMOTIVE SAXDER.A sand box and chute with a nozzleby which compressed air from the air-brake reservoir blows the sand into thedischarge pipe. 568. MULTIPLE PLATE FRICTIOXCLUTCH. Pattern of the main drivingshaft clutch, Brooklyn Bridge. Every otherring plate is keyed to the inner sleeve…

Mechanical movements
