Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 235

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 235
598. CAR COUPLER. Washburn type.Has the side movement of the draw bar, andalso a movement of the head of the couplercontrolled by the side thrust of the helicalsprings for centering the coupler head. … 599. BULLDOZER PRESS. Forquickly bending straps and braces ofiron or steel for car and other construct-ive work. In this way a large numberof forming blocks are used of differentdesigns to fit the slides of the machine. 599A. HAND-CARDRIVEN BY MOTOR-CYCLE. The 2}A hp. motorcycle is mountedon a…

Mechanical movements
