Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 241

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 241
:::. INTERMITTENT ROTARY MOTION by a triangularcam on a rotating shaft The cam works in a yoke forming part of a sliding and vibratory lever dog,the opposite ends of which areadapted to alternately engagewith the teeth of the crown-gearwheel, one end of the vibratorylever do? bein? held bv a…
