piston stroke.The eccentrics are at 90° and 180°, as shown at a. The three pistonvalves are directly connected by rods to thin straps on an angularlymounted cylinder that slides on the shaft by the hand lever for for-ward, stop, or reverse motion. Piston valves are used, taking the steam in the… … 163. TYPES OF SLIDEVALVES. Slide valve of theAmes engine. The valve is fin-ished on both sides and rides undera partly balanced pressure plate. STEAM POWER APPLIANCES. 8l 164. BALANCED PISTON VALVE. The segmental packing,E, is held close to the cylinder wall by the pressure of the steam which…
