Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 252

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 252
TUTE. The shaft to bedriven has recesses in which are pawls or frictiondevices, two rings being placed on the sleeve hav-ing internal ratchets when pawls are used, whilebands are connected to the rings and to a frame sothat when the frame is moved downward one of therings on the sleeve will move… … 641. SHORT-RANGE WALKING BEAM. By the interlocking linkage the cylinder andcrank can be brought close together. None of the motions in this linkasre areparallel. The piston rod is the guide to thelast link.

Mechanical movements
