658. MULTIPLE BALL BEAR-INGS, for vehicles. The four rings ofballs A, A, A, A, are held in place by thering cones, B, B, B, B, and the wholeheld in place by the nut and check nut D.C, C, channel sleeves that give the ballsa three point bearing. … 659. SHAFT-THRUST BALL BEARINGS on a vertical shaft. A, A, grooved rings with out-side conical bearings. D, a spherical bearing collarresting on the foot flange C. F, retaining collar.The balls have four point bearings. 252 MOTION AND CONTROLLING DEVICES, ETC.
