Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 261

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 261
length. Of thiskind is A, in which the piece a to becut is moved longitudinally throughthe holder b, and at the same time isrotated so that the tool c in its revolu-tions may cut the spiral groove shownat a. 679. B is a fluting lathe in whicha pair of cutters revolve in a planeoblique with the line… … MOTION AND CONTROLLING DEVICES, ETC. 257

Mechanical movements
