Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 264

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 264
SPINDLE^^Sk- CLOSER SPRING CHUCK ADJUSTMENT FOR SPINDLE SECTION OF SPINDLE. 684. Plan. 685. Section of spindle. MOTION AND CONTROLLING DEVICES, ETC. 259 … SECTION AND EXAMPLES. 686. Tool post, rose wheel and cutting tool at the work at H, onthe face plate of the lathe. 687. Examples of curved figures made by different forms of rosewheels. 688. PLANETARIUMS. In the lower planetarium the globe rep-resenting the sun is supported on a central shaft,…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
