Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 268

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 268
races are very finely finished and are made of special alloy steeland hardened. SECTION XVI. HOROLOGICAL, TIMEDEVICES, ETC. 262 Section XVI.HOROLOGICAL, TIME DEVICES, ETC. … 691. ELECTRIC PENDULUM. P P is the pendulum, W a weight,mounted on a lever, W C A. W C A can move about a center, C, and is at present prevented from turn-ing by the catch, S S. When P Pswings to the right, the lowerscrew in P P passes under E (seeside view Z) and frees W C A.W C A, under the…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
