Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 27

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 27
imade for rewinding thebelt on the drum aftereach pull on the drivinglever, with a ratchet torelease the drum andpermit it to run free on the driving shaft while the vehicle is under way.The feet are used to steer the wagon, two sliding braces being placed onthe floor within easy reach, excess… … Section II.TRANSMISSION OF POWER.

Mechanical movements
