Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 288

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 288
A pair of heavy rollers in a cir-cular trough rollsthe briquet mate-rial into the holesof a revolving moldplate, in which thebriquets receivea further pressureand are ejected onto a belt carrier,which depositsthem in a truck orbin. Type of theChisholm, Boyd &White Co., Chi-cago, 111. … 737. COAL-WASHINGJIG. Coal and slate arewashed through a vibratingbox or jig, and separatedby their difference in grav-ity. The coal is carriedover in a short chute tothe coal elevator and theslate is discharged throughan adjustable trap to theslate hopper below, fromwhich it is carried away byan…

Mechanical movements
