Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 293

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 293
AND FACTORY APPLIANCES AND TOOLS, ETC. 745. DRILL CHUCK for small drills. A section. By revolvingthe knurled nut the jaws are moved outward or inward in the converging slots in the chuck body as may be de-sired. The chuck can be operated byhand, and when a very firm grip is de-sired it may be…

Mechanical movements
