Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 293

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 293
TOOLS. One of the handiest toolsfor a farmer or amateurworkman is this combinationof an anvil, vise, and a drillstock. … 748. EASILY MADE STEAM WHISTLE. A, a brass casting into which the bell stem may be screwed. B, a tube of the same diameter as the bell, soldered tothe casting, A, leaving an annular opening /wo of an inch. C, the bell which may be cast or made of the sametubing as at B, with a headpiece, D,…

Mechanical movements
