Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 295

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 295
MILL AND FACTORY APPLIANCES AND TOOLS, ETC. 291 758. CENTERING DEVICE FOR A DRILL PRESS. Thedevice consists of a drill shank, A,made to fit the drill spindle; a centering vise with three jaws, two of which areindicated by C, and a chuck to holdthe combined drill and reamer D.The centering jaws are…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
