Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 297

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 297
lliptic cylinders of considerable|pa length the cylinder may move forward parallelwith the fixed boring bar on which a fixed spool,A, is set at the angle required by the elliptic pro-portions of the cylinder, and upon which a ring,H, and tool holder revolve by a bevel gear andpinion, R, driven by… … 761. C R A X E TRUCK. One of thehandy things in a shop or warehouse. Withwindlass chain and block two tons may be liftedand easilv wheeled over the floor.

Mechanical movements
