ft. 2i in. long, with two journalsat the ends, and one at the center between the driving ropepulleys. In the bosses of these pulleys the shaft is swelled to16 in. in diameter. The rope wlieels, which are two in num-ber, are 6ft. U in. pitch diameter; they are made in halvesand are each grooved for… … Fig. -Grip. rope shaft arc 25 ft. in diameter, built upof ten segments each, with a liollow bossin one piece, and ten hollow arms ofelliptical section. The shaft which car-ries tliese wheels is 16 ft. 11 in. long, thediameter in the boss of the wheels being19^ in. This shaft is coupled at each…
