Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 32

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 32
gedthat the rod acts as a dou-ble buffer to the carrier,each of its ends beingadapted to strike a stopblock, two of which areattached to the wire, one at each end. Near each end of the bar is apawl, acted upon by a spring which lifts its free end so it will auto-matically engage with a lip formed…

Mechanical movements
