Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 330

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 330
hetwo drums and four spools haveeach an independent motion andstop. 838. DISINTEGRATOR. Blanchard type. On two concentricshafts driven at high speeds are mounted grids or cages, one within the other, driven in oppositedirections. F, the feedhopper. E, a steel pinprojecting within the in-ner cage to… … 326 ENGINEERING AND CONSTRUCTION, ETC. Slates

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
