Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 336

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 336
856. FALL ROPECABLE CARRIER. Miller type. Five-ropesystem without fall latch.The power of the hoistrope is increased threetimes at the fall block. 857. Section of a per-manent button stop withpin and holes for soldering. THE BUTTON … TRACTION ROPEMAIN CABLERACTION ROPECARRIAGE 858. FALL ROPE CA-BLE CARRIER. Four-rope system with loop blocksto support the fall rope. The traction rope is anendless one, driven fromone end of the carrier plant.The lift is three times thepower of the fall rope. 332 ENGINEERING AND CONSTRUCTION, ETC.…

Mechanical movements
