Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 338

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 338
ovided at its right-hand extremity with a pinion 2J feet in diameter. This engages witha small pinion that is mounted on the shaft that is rotated by the endlesschain from below. The draw is almost balanced by the weight of therollers. 861. TRANS-FER BRIDGE.A hanging trackon an…

Mechanical movements
