Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 346

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 346
ording to the velocity given the instrument andto the nature of the ground plowed. As may be seen, the colter disksare mounted on the back of the locomotive, and the inclination of thecolters as well as the rotation of the disks is in a contrary direction inorder to assure the pulverization, which… … 873. REVERSIBLE PLOW. The wheel runs in the last furrow.y, yoke handle, which turns over tothe other side at the end of a fur-row ; V, latch to fasten the handleto the beam ; /, k, clevis and chain. 874. TETHERINGlb

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
