Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 347

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 347
877. POTATO-RASPING MA-CHINE. Used in the manufacture ofstarch, a, hopper ; b, barrel rasp ; c,receptacle for pulp ; d, wooden buffer ;e, setting screw ; /, water jet. The buffer is for adjusting the open-ing between the rasping barrel anditself to insure a uniformly fine potatopulp. 878.… … 879. AUTOMOBILE MOWING MACHINE. McCormick type.The motor is a double cylinder, 10-horse-power gasoline engine. The oil tank is dividedinto three compart-ments : one for oil,one for batteries, andone for water. Poweris transmitted fromthe motor by sprocketwheels and chain toa friction clutchplaced…

Mechanical movements
