Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 347

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 347
r gasoline engine. The oil tank is dividedinto three compart-ments : one for oil,one for batteries, andone for water. Poweris transmitted fromthe motor by sprocketwheels and chain toa friction clutchplaced on the crossshaft of the mower.This clutch is so ar-ranged as to engageeither one… … MISCELLANEOUS DEVICES. 343 They also transmit power to the mower wheels through two gearwheels. The friction clutch is controlled by a lever placed at the footof the operator. Steering is effected by a crank connected with theguide wheel in front of the cutter bar. The cutter bar can be lifted…

Mechanical movements
