Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 348

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 348
MISCELLANEOUS DEVICES. 343 They also transmit power to the mower wheels through two gearwheels. The friction clutch is controlled by a lever placed at the footof the operator. Steering is effected by a crank connected with theguide wheel in front of the cutter bar. The cutter bar can be lifted… … lever. The main feature of thesemowers is the floating cutter frame,which permits setting the cutterbar at the desired height; and uphill and down dale, through hol-lows and over ridges, it will cutall the grass at the same height, until re-adjusted.On all themowersthe gearing is protected from…

Mechanical movements
