Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 351

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 351
which air, in addition to that entering through thefire bars, is forced ; 7 and jb, on either side of ja, are not visible in cut;the refuse to be burned is fed throughthe aperture 9. The stoking hole,10, permits the introduction of an iron bar for keeping the grate and backwall, 5, from getting…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
