Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 361

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 361
The wheel is then movedforward until at the proper time the wrapped article is ejected by plun-gers. 903D. ROTARY ENGINE, HOFFMAN TYPE. The cylinder Arevolves around the stationary ellipse E, which is permanently attachedto the hollow shaft S. Steam is admitted through the hollow shaft Sduring the… … mental blade B, which runs the length of the cylinder, can retreat intoits housing D and is fastened by a crank G to the cylinder. A curvedsegmental blade is like a section of a pipe cut lengthwise. Steam pres-sure on the blade causes it to recede to the right, away from the port F,and thus the…

Mechanical movements
