Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 362

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 362
ached to the segmental blade, isforced to revolve. As the cylinder revolves it presses down upon thestationary ellipse E, and the blade B is forced back into its housing Djust as the blade C is in its housing H at the beginning of the movement.Meanwhile the blade C, which is the duplicate of the… … 904. GEOMETRICAL PEN. Suardis type. In the gear pro-portion, as shown, the diameter of a is half of that of A ; these wheels are connected by the idler, E, whichmerely reverses the direction with-out affecting the velocity of as rota-tion. The working train arm isjointed so as to pivot about…

Mechanical movements
