Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 382

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 382
N. Extending weights and watertransfer. The stationary sector gear, A, rolls the small pinions which, by a rod connection with thefollowing edge of the hingedweights on the periphery of thewheel, tilt the weights upwardand outward, making a prepon-derance on that side of the wheel.The same…

Mechanical movements
