Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 383

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 383
sitions of the — band and chain be in equilibrium with the hypotenuse, on the principle of the inclined plane. The framein which these rollers are fixed is placed in a cistern of water havingits lower part immersed. On the perpendicular side of the triangle, the weights hanging per-pendicularly… … PERPETUAL MOTION. 379 thereby create a load, which load will not exist on the ascending side,because on this side the chain of weights compresses the band at thewaters edge, and squeezes out any water that may have previously ac-cumulated in it, so that the band rises in a dry state, the weight of…

Mechanical movements
