Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 391

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 391
t, while this is goingon, the upper end of the large magnet raises,by means of a guide wire, the tumbler D,which, just before the magnets come incontact, passes the perpendicular, and fallsover, carrying with it the lever connected with the two wheels, C, C, andcausing them to perform a quarter… … PERPETUAL MOTION. 3*7 964. PERPETUAL MOTION. Magnetic wheel. A light wheelon friction rollers, set with slips of iron at an angle around its periphery. N, N are two magnets, which, attracting the rimof the wheel, will render one side lighter and theother heavier, causing it to revolve ad…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
