Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 393

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 393
heel. The star wheel isarranged to tilt a lever, whichcarries at its extremity a plate,B, of brass coated with thechemical and mineral sub-stances which make it an in-sulator of magnetism. The per-manent magnet is a U-shapedbar, with its poles near the wheel,A, and opposite the path of… … PERPETUAL MOTION. 389 968. PERPETUAL MOTION. Alternate magnet type. The swing-ing of the outside magnets of oppositepolarity. Alternate the attraction andrepulsion of the magnets on the wheelto generate power to swing the outsidemagnets in and out of their sphere of_*2\I v--JL-^/^ |i/^o action.…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
