Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 45

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 45
balancing lever and connections ; A, air inlet cylinder ; B, lamp chim-ney, all of sheet iron ; O, damper rod ; D, wick rod. 40 MEASUREMENT OF POWER. SPRINGS. … 48. METALLIC THERMOMETER. The instrument dependsfor its operation on the (inference between the expansion of brass and steel. The linear expansion ofbrass is greater than that of steel, so that when a curved bar ofbrass is confined at the ends by astraight bar of steel, the brass barwill elongate…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
