Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 46

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 46
e tubes, a, b,I?1, which connect freely with one another,and are mounted vertically between conicalcenters. The tubes are sealed air tight sothat no liquid can escape or be added. Ascale is placed on a standard opposite thecentral glass tube, and is graduated to cor-respond to various speeds. When… … 42 MEASUREMENT OF POWER, SPRINGS. 54. HYGROSCOPE. In the instrument a strand, H, of hair, de-prived of all fat, is secured at its upper end at f, and at its lower endto a crank, k, carried by the shorter and heavier arm,g, of an angle-lever pivoted at O. The longer andlighter arm of the lever…

Mechanical movements
