Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 67

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 67
te and furnishan annular stream of vapor gas from thechamber below. 106. AUTOMOBILE BOILER. Showing the arrangement ofburner and vaporizing coil above the burner tubes. The gasoline is fed to andvaporized in the spiral coil. Thevapor injected into the burnerchamber by the valve B carriesair with… … 107. FUEL OIL BURNER. Plan and sections of the crudeoil burners used on the locomotives of the Southern Pacific Railroad.
