by aspiration so as to induce currents to draw out fromthe condenser by this action the air which gathers in it andwhich lacks a barometric balance. The small pipe H drawsthe heated water for the boiler from the hot-well. It will be seen that this gravity or barometric condenserdispenses with the… … FiG. 76. pump is comparatively small, and it requires little power torun it. The difficulty with the Ransom condenser was thetrouble from the air. The pot had to be very tight, and theaspiration devices were not entirely satisfactory. 55. The Siphon or Injector Condenser.—Belonging tothe class of…
