Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 68

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 68
114. OIL FUEL BURNER. … An English type of approveddesign in whichthe steam issues inan annulus withinan annulus of oiland air at thethroat of a doublecone. Designedfor the most eco-nomical combus-tion of oil. 64 GENERATION OF POWER, STEAM. 115. FUEL OIL BURNER. An air burner. Brown type.The air issues in an annular…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
